KEO 930 Solid Carbide G-Mill DIA-12mm × 60mm 10x Reach Length 3 Flute 5xD Flute Length Square Amorphous Diamond Coated
| Cutting Diameter (DC) | 12 mm | Flute Count (NOF) | 3 |
| Connection Diameter Machine Side (DCONMS) | 12 mm | End Shape | Square |
| Depth of Cut Maximum (APMX) | 60 mm | Tool Type | Single-End |
| Overall Length (OAL) | 150 mm | Length Group | Extra Reach |
| Cutting Edge Material | Carbide | Decimal Equivalent | 0.4724″ |
| Coating | Amorphous Diamond |
Product Features
| Remarks | •35° Helix •AD (Amorphous Diamond) coated "G" Mills are specifically designed for machining graphite electrodes. •"G" Mills have been shown to be a cost effective solutions in producing graphite electrodes by lowering tooling costs and improving productivity. •Designed with a Fast Helix and 3 flute design, "G" Mills outperform conventional end mills by providing faster particle evacuation while producing extremely smooth finishes in graphite. •"G" Mills are factory laser inspected to ensure more accurate machining of graphite electrodes. | Country of Origin | USA |
Shipping Info
Package Weight
0.01
