EC015E04-3C04 IC300
Square End Mill; 1.5 mm Dia. × 4 mm LOC × 4 mm Shank Dia. × 50 mm OAL ; 3 FL ; Carbide ; TiCN
| Cutting Diameter (DC) | 1.5 mm | Application | Counter Boring | Drill Mill | Helical Interpolation | Plunging & Recessing | Rampdown | Shouldering | Slotting |
| Connection Diameter Machine Side (DCONMS) | 4 mm | Ramping Angle Maximum (RMPX) | 5 Degrees |
| Depth of Cut Maximum (APMX) | 4 mm | Grade | IC300 |
| Overall Length (OAL) | 50 mm | Tool Type | Solid carbide center cutting endmills 90 Degrees |
| Cutting Edge Material | Carbide | Maximum Feed per Tooth (fz(max)) | 0.02 mm/tooth |
| Coating | TiCN | Minimum Feed per Tooth (fz(min)) | 0.01 mm/tooth |
| Flute Count (NOF) | 3 | Body Material | Carbide |
| Flute Helix Angle (FHA) | 38 Degrees | Decimal Equivalent | 0.035″ |
| Shank Type | Round | Measurement Type | Metric |
| End Shape | Square | Connection Code Machine Side (CCMS) | Cylindrical |
| Applicable Material | | Steel | Stainless Steel | Hi Temp Alloys | |
Product Features
| Family Description | 3 flute, 38° helix medium length solid carbide endmills. | Country of Origin | Israel |
| Remarks | Multi-purpose endmill. Suitable for deep slotting. |
Shipping Info
Package Weight
0.022
