EC-A2 07-08W08E58 IC08
| Cutting Diameter (DC) | 7 mm | Application | Drill Mill | Helical Interpolation | Plunging & Recessing | Rampdown | Shouldering | Slotting |
| Connection Diameter Machine Side (DCONMS) | 8 mm | Ramping Angle Maximum (RMPX) | 5 Degrees |
| Depth of Cut Maximum (APMX) | 8 mm | Grade | IC08 |
| Overall Length (OAL) | 58 mm | Tool Type | Solid carbide center cutting endmills 90 Degrees |
| Cutting Edge Material | Carbide | Maximum Feed per Tooth (fz(max)) | 0.08 mm/tooth |
| Coating | Uncoated | Minimum Feed per Tooth (fz(min)) | 0.03 mm/tooth |
| Flute Count (NOF) | 2 | Length Group | Short|Stub |
| Flute Helix Angle (FHA) | 30 Degrees | Body Material | Carbide |
| Shank Type | Weldon | Decimal Equivalent | 7 mm |
| End Shape | Square | Measurement Type | Metric |
| Applicable Material | Non Ferrous Metals | |
Product Features
| Family Description | Economical type 2 flute, 30° helix center cutting, short/medium/extra long length solid carbide endmills. | Country of Origin | Israel |
Shipping Info
Package Weight
0.095
