| Thread Diameter Size (TDZ) | 1/2″ | Coolant Supply Property (CSP) | External |
| Threads per Inch (TPI) | 14 | Cutting Direction (HAND) | Right Hand |
| Thread Standard | BSP | Applicable Material | | Cast Iron | |
| Usable Length (LU) | 80 mm | Coating | Nitride |
| Flute Count (NOF) | 5 | Cutting Edge Material | HSSCo |
| Overall Length (OAL) | 125 mm | Standard | DIN5156 |
| Thread Cutting Part Length (THL) | 24 mm | Series/List # | E4161/2 |
| Connection Diameter Machine Side (DCONMS) | 16 mm | Thread Size | 1/2″ - 14 |
| Flute Type | Semi-Bottoming |
Product Features
| Country of Origin | Germany |
Shipping Info
Package Weight
.4400
