HP E90AN-D25-7-W25-07
Endmills using HELIPLUS HP ANKT 0702.. inserts. Extra fine pitch endmills with very tight tool and insert tolerances for high production rates. Very strong and durable insert. Available are tools with and without coolant holes.
| Cutting Diameter (DC/DCX) | 25 mm | Head Length (LH) | 24 mm |
| Cutting Diameter (DC) | 25 mm | Tool Type | 90° Indexable End Mill |
| Cutting Item Count (CICT) | 7 | Usable Length (LU) | 24 mm |
| Depth of Cut Maximum (APMX) | 7.7 mm | Flute Count (NOF) | 4 |
| Overall Length (OAL) | 95 mm | Coolant Supply Property (CSP) | External |
| Shank Type | Weldon | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Ramping Angle Maximum (RMPX) | 2.1 Degrees | Cutting Direction (HAND) | Right Hand |
| Application | | Helical Interpolation | Rampdown | Shouldering | Slotting | | Measurement Type | Metric |
| Connection Diameter Machine Side (DCONMS) | 25 mm | Body Material | Steel |
| Master Insert Identification (MIID) | HM390 TDKT 1505PDR | Connection Code Machine Side (CCMS) | Cylindrical |
| Weight of Item (WT) | 0.73 Kg |
Product Features
Family Description
Endmills using HELIPLUS HP ANKT 0702.. inserts. Extra fine pitch endmills with very tight tool and insert tolerances for high production rates. Very strong and durable insert. Available are tools with and without coolant holes.
Remarks
Insert tightening torque: 62 Nxcm For adaptation click on "More Info".
Country of Origin
IL
Shipping Info
Package Weight
.8330
