1355 PAR FLT JBBR DRL NO. 21

Item # MT7813298

Brand: Morse Cutting Tools

MFG #: 13298

Legacy Part #: MT7813298

UPC #: 01039756 | 68612513298 | 686125132989

TradeName: HSS-GP

Quantity Available

Drill Bit Size / Cutting Diameter (DC)

#21

Cutting Depth

‎2-1/8″

Decimal Equivalent

0.1590

Flute Length

‎2-1/8″

Measurement Type

Wire Gauge

Point Shape

Split

Angle

135 Degrees

Shank Type

Straight

Cutting Edge Material

HSS

Connection Diameter Machine Side (DCONMS)

0.159″

Flute Type

Parabolic

Shape

General Purpose

Coating

Bright

Series/List #

1355

Coolant Supply Property (CSP)

External

Overall Length (OAL)

‎3-1/4″

Product Features

Remarks

Parabolic Flute Jobber Length Drills• Parabolic Flute drills feature a unique flute design that greatly enhances chip flow, coolant flow to the drill point and heat dissipation in deep hole drilling greater than three diameters deep• Recommended for drilling aluminum and other low to medium tensile strength materials• Bright Finish with polished flutes enhances chip ejection especially for aluminum and other non-ferrous materials.

Country of Origin

USA

Shipping Info

Package Weight

0.02
