4 Flute - Taper - 0.7500″ (3/4) Cutter DIA × 0.7500″ (3/4) Shank DIA × 54.0000″ Major Radius × 0.0938″ Tip Radius × 0.3750″ (3/8) Corner Radius × 0.6562″ (21/32) LOC × 4.0000″ (4) OAL - NPLUS Coated
Tapered End Mill; 3/4″ Dia. × 21/32″ LOC × 4″ OAL × 3/4″ Shank Dia. ; 4 FL ; 60 Degrees ; Carbide
| Applicable Material | | Aluminum / Non-Ferrous Materials | | Body Half Taper Angle (BHTA) | 30 Degrees |
| Cutting Diameter (DC) | 3/4″ | Point Angle (SIG) | 60 Degrees |
| Depth of Cut Maximum (APMX) | 21/32″ | Cutting Edge Material | Carbide |
| Flute Count (NOF) | 4 | End Shape | Taper |
| Overall Length (OAL) | 4″ | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Tool Type | Tapered |
Product Features
| Country of Origin | USA |
Shipping Info
Package Weight
0.8
