5.00x14.00 MM Dormer HSS Bright 122 Centre Drill - 60 Short Center E-code # A2015.0X14.0
Drill Bit; 14 mm Dia. × 78 mm OAL ; 122 Degrees ; Round Shank ; HSS ; Uncoated ; Series A201
Additional Tariff Surcharge of 8 %
| Drill Bit Size / Cutting Diameter (DC) | 14 mm | Application | Centre Drills |
| Decimal Equivalent | 0.5512 | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | Aluminum / Non-Ferrous Materials | Other Non-Metallic Materials | |
| Drill Bit Size / Cutting Diameter (DC) - Metric | 14 mm | Flute Length | 7.7 mm |
| Point Angle (SIG) | 122 Degrees | Point Diameter (PDD) | 5 mm |
| Angle | 60 Degrees | Length Group | 1D | Short/Stub |
| Overall Length (OAL) | 78 mm | Cutting Direction (HAND) | Right Hand |
| Shank Type | Round | Tool Type | Center Drill |
| Coating | Uncoated | Series/List # | A201 |
| Cutting Edge Material | HSS |
Product Features
| Family Description | E-code # A2015.0X14.0 | Country of Origin | France |
Shipping Info
Package Weight
0.286
