KEO 906 HSS PLain Type Metric Centerdrill DIN 333-A DIA-4.0mm Pilot 10.0mm Body Uncoated
Drill Bit; 10 mm Dia. × 56 mm OAL × 10 mm Shank Dia. ; 60 Degrees ; Round Shank ; HSS ; Uncoated
| Style | Plain | Cutting Edge Material | HSS |
| Drill Bit Size / Cutting Diameter (DC) | 10 mm | Nose Length | 5 mm |
| Point Angle (SIG) | 60 Degrees | Flute Length | 5 mm |
| Angle | 60 Degrees | Size | 4 mm |
| Overall Length (OAL) | 56 mm | Point Diameter (PDD) | 4 mm |
| Connection Diameter Machine Side (DCONMS) | 10 mm | Measurement Type | Metric |
| Shank Type | Round | Tool Type | Combination Drill & Counter Sink |
| Coating | Uncoated | Cutting Length | 5 mm |
Product Features
| Remarks | •Metric CombinedDrills & Countersinks •Type A 60° Plain TypeHigh Speed Steel •Standard metric sizes according to DIN333 specifications.(All dimensions in metric mm). | Country of Origin | USA |
Shipping Info
Package Length
2.22000
Package Width
.39000
Package Height
.39000
Package Weight
0.05
