| Thread Pitch (TP) | 1.588 mm | Flute Helix Angle (FHA) | 15 Degrees |
| Threads per Inch (TPI) | 16 | Cutting Edge Material | Carbide |
| Thread Standard | UNF |THFT | | Cutting Position | Internal |
| Connection Diameter Machine Side (DCONMS) | 12 mm | Series/List # | MTB |
| Cutting Diameter (DC) | 12 mm | Measurement Type | Metric |
| Functional Length (LF) | 39 mm | Grade | IC908 |
| Overall Length (OAL) | 84 mm | Tool Type | Solid carbide thread mills |
| Flute Count (NOF) | 4 | Depth of Cut Maximum (APMX) | 31 mm |
| Coolant Supply Property (CSP) | Coolant Thru | Cutting Direction (HAND) | Left Hand|Right Hand |
| Shank Type | Round | Body Material | Carbide |
| Coating | TiAlN | Connection Code Machine Side (CCMS) | Cylindrical |
| Application | | Internal Thread Milling | | Thread Form Type (THFT) | UN60 |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
Product Features
| Family Description | Solid carbide threading endmills with coolant hole for internal UN thread profile. | Country of Origin | Israel |
Shipping Info
Package Weight
0.267
