48Y200ISS7RA410 IN2005
| Thread Size | 16 | Application | | External Thread Milling | Internal Thread Milling | |
| Thread Pitch (TP) | 2″ | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Non Ferrous Metals | Hi Temp Alloys | |
| Thread Standard | ISO | Cutting Edge Material | Carbide |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Cutting Position | Internal |
| Cutting Diameter (DC) | 0.75 | Usable Length (LU) | 1.61″ |
| Functional Length (LF) | 39 mm | Series/List # | MTB |
| Overall Length (OAL) | 4″ | Measurement Type | Inch |
| Flute Count (NOF) | 6 | Grade | IN2005 |
| Coolant Supply Property (CSP) | Coolant Thru | Cutting Direction (HAND) | Left Hand|Right Hand |
| Coating | TiAlN | Body Material | Steel |
Product Features
| Country of Origin | Israel |
Shipping Info
Package Weight
0.008
