MITR 8-MT1-0.05 IC908
| Thread Standard | THFT | | Thread Pitch Minimum (TPN) | 0.75 mm |
| Corner Radius (RE) | 0.002″ | Thread Pitch Maximum (TPX) | 1.25 mm |
| Grade | IC908 | Cutting Edge Length (L) | 0.226″ |
| Coating | TiAlN | Profile Included Angle (PNA) | 60 Degrees |
| Cutting Edge Material | Carbide | Insert to Shank Reference | 0.75 mm |
| Cutting Position | Internal | Tool Type | Groove-Turn Precision Inserts |
| Cutting Direction (HAND) | Right Hand | Measurement Type | Inch |
| Application | | Threading (Int.) | | Body Material | Carbide |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | | Thread Form Type (THFT) | M60 |
| Minimum Bore Diameter (DMIN) | 0.394″ |
Product Features
| Family Description | MINCUT Internal partial profile ISO metric threading inserts for .394″ minimum thread diameter. | Country of Origin | Israel |
Shipping Info
Package Weight
0.006
