TR6 TNMU 100415 IC882
Milling Insert; TR6 TNMU 100415 IC882 INS IC882 × 0.165″ Thickness ; Carbide ; AlTiN+TiAlSiN+TiSiN
| Applicable Material | | Stainless Steel | Super-Alloys / Titanium | | Shape | Round |
| Application | | Facing | Profiling | Undercutting | | Maximum Feed per Tooth (fz(max)) | 0.3 mm/tooth |
| Corner Radius (RE) | 1.5 mm | Cutting Direction (HAND) | Neutral |
| Depth of Cut Maximum (APMX) | 1.5 mm | Cutting Edge Material | Carbide |
| Inscribed Circle Diameter (IC) | 7.3 mm | Minimum Feed per Tooth (fz(min)) | 0.1 mm/tooth |
| Insert Thickness (S) | 4.2 mm | Measurement Type | Metric |
| Coating | AlTiN+TiAlSiN+TiSiN | Body Material | Carbide |
| Grade | IC882 |
Product Features
| Family Description | Double-sided inserts with six round cutting edges, available in 0.5 up to 3.0 mm corner radii. | Country of Origin | Israel |
Shipping Info
Package Weight
0.009
