SDHW 100408-TN-CS IC5820
Milling Insert; 0.394″ Length × 0.177″ Thickness ; IC5820 ; TiCN+Al2O3+TiCN
| Applicable Material | | Stainless Steel | Super-Alloys / Titanium | | Shape | Round |
| Application | | Shouldering | Slotting | | Maximum Feed per Tooth (fz(max)) | 0.0047 ″/tooth |
| Cutting Edge Length (L) | 0.394″ | Cutting Direction (HAND) | Neutral |
| Insert Length (INSL) | 0.394″ | Tool Type | Mill AL, HTA Geometric Inserts |
| Corner Radius (RE) | 0.0315″ | Minimum Feed per Tooth (fz(min)) | 0.002 ″/tooth |
| Inscribed Circle Diameter (IC) | 0.394″ | Number of Cutting Edges | 4 |
| Insert Thickness (S) | 0.177″ | Measurement Type | Inch |
| Coating | TiCN+Al2O3+TiCN | Body Material | Carbide |
| Grade | IC5820 |
Product Features
| Family Description | Square inserts for general use applications carried on SDK extended flute cutters. | Country of Origin | Israel |
Shipping Info
Package Weight
0.009
