FFQ4 SOMT 170625T IC810
Milling Insert; 17.5 mm Length × 6 mm Thickness ; IC810 ; Carbide ; AlTiCrN+TiN
| Applicable Material | | Steel | Cast Iron | | Shape | Round |
| Application | | Facing | Fast Feed Milling | Helical Interpolation | Plunging & Recessing | Profiling | Rampdown | Side Plunging | | Maximum Feed per Tooth (fz(max)) | 2 mm/tooth |
| Cutting Edge Length (L) | 17.5 mm | Cutting Direction (HAND) | Neutral |
| Insert Length (INSL) | 17.5 mm | Cutting Edge Material | Carbide |
| Corner Radius (RE) | 2.5 mm | Tool Type | Single sided Inserts |
| Insert Thickness (S) | 6 mm | Minimum Feed per Tooth (fz(min)) | 0.4 mm/tooth |
| Insert Included Angle (EPSR) | 90 Degrees | Number of Cutting Edges | 4 |
| Coating | AlTiCrN+TiN | Measurement Type | Metric |
| Grade | IC810 | Body Material | Carbide |
Product Features
| Family Description | Single-sided square inserts with 4 cutting edges for fast feed milling. | Country of Origin | Israel |
| Remarks | For side plunging, the initial cutting feed is 0.1 mm/t T type for steel, ferritic and martensitic stainless steel and cast iron RM-.. type for interrupted cut and machining near straight shoulder walls HP type for austenitic stainless steel and high temperature alloys TFW type for unstable cutting conditions SOMW- flat insert for hard material (up to 60 HRC) and uneven surface |
Shipping Info
Package Weight
0.05
