FPKT 1604PDR-76 IC928
| Applicable Material | | Steel | Stainless Steel | Hi Temp Alloys | | Shape | 85° Parallelogram |
| Application | | Countersinking | Facing | Milling Inserts | Plunging & Recessing | Rampdown | Shouldering | Slanted Shoulder & Chamfer | Slotting | | Maximum Feed per Tooth (fz(max)) | 0.2 mm/tooth |
| Cutting Edge Length (L) | 17.3 mm | Cutting Direction (HAND) | Right Hand |
| Insert Length (INSL) | 17.3 mm | Cutting Edge Material | Carbide |
| Corner Radius (RE) | 0.8 mm | Tool Type | Single sided Inserts |
| Depth of Cut Maximum (APMX) | 15.3 mm | Minimum Feed per Tooth (fz(min)) | 0.1 mm/tooth |
| Insert Width (W1) | 9.45 mm | Cutting Edge Effective Length (LE) | 15.3 mm |
| Insert Thickness (S) | 5.3 mm | Measurement Type | Metric |
| Coating | TiAlN | Body Material | Carbide |
| Grade | IC928 |
Product Features
| Family Description | Milling inserts with a 16 mm cutting edge length and a positive rake angle for general use. | Country of Origin | Israel |
Shipping Info
Package Weight
0.018
