SWMT1506ZER-MJ AH120
Milling Insert; SWMT1506ZER-MJ AH120 AH120 × 0.627″ Width × 0.268″ Thickness ; Carbide ; TiAlN
| Applicable Material | Steel |Stainless Steel |Cast Iron |Hard Materials |Hi Temp Alloys | | Shape | Round |
| Application | | High feed Milling | | Maximum Feed per Tooth (fz(max)) | 0.079 in/tooth |
| Corner Radius (RE) | 7.94 mm | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 0.098″ | Tool Type | Single sided Inserts |
| Insert Width (W1) | 0.627″ | Minimum Feed per Tooth (fz(min)) | 0.012 in/tooth |
| Inscribed Circle Diameter (IC) | 0.627″ | Cutting Edge Effective Length (LE) | 0.627″ |
| Insert Thickness (S) | 0.268″ | Measurement Type | Inch |
| Coating | TiAlN | Body Material | Carbide |
| Grade | AH120 |
Product Features
| Family Description | Single-sided square insert with MJ chipbreaker | Country of Origin | Japan |
Shipping Info
Package Weight
0.039
