DPM434R001 IN4030
Milling Insert; 0.709″ Length × 0.551″ Width × 0.3″ Thickness ; IN4030 ; Carbide ; TiCN
| Applicable Material | | Steel | Stainless Steel | Hi Temp Alloys | | Shape | Round |
| Application | | Facing | Milling Inserts | Profiling | | Insert Style | DPM434R001 |
| Cutting Edge Length (L) | 0.709″ | Maximum Feed per Tooth (fz(max)) | 0.25 mm/tooth |
| Corner Radius (RE) | 0.031″ | Cutting Edge Material | Carbide |
| Insert Width (W1) | 0.551″ | Tool Type | Single sided Inserts |
| Insert Thickness (S) | 0.3″ | Minimum Feed per Tooth (fz(min)) | 0.15 mm/tooth |
| Coating | TiCN | Measurement Type | Metric |
| Grade | IN4030 | Body Material | Carbide |
Product Features
| Family Description | DPM434R001 | Country of Origin | USA |
Shipping Info
Package Weight
0.05
