XFEB330550L-P IN15K
Milling Insert; XFEB330550LP IN15K IN15K 0.635″ Length × 1.3″ Width × 0.23″ Thickness ; Carbide
| Applicable Material | Cast Iron|Non-Ferrous Metals | Shape | Round |
| Application | | Facing | Milling Inserts | Profiling | | Insert Style | XFEB330550L-P |
| Cutting Edge Length (L) | 0.635″ | Maximum Feed per Tooth (fz(max)) | 0.25 mm/tooth |
| Corner Radius (RE) | 0.197″ | Cutting Edge Material | Carbide |
| Insert Width (W1) | 1.3″ | Tool Type | Single sided Inserts |
| Insert Thickness (S) | 0.23″ | Minimum Feed per Tooth (fz(min)) | 0.15 mm/tooth |
| Coating | TiCN | Measurement Type | Metric |
| Grade | IN15K | Body Material | Carbide |
Product Features
| Family Description | XFEB330550L-P | Country of Origin | USA |
Shipping Info
Package Weight
0.08
