UNEU1205R IN2530
| Applicable Material | Steel|Stainless Steel|Cast Iron|Hi-Temp Alloys | Shape | Round |
| Application | | Facing | Milling Inserts | Profiling | | Insert Style | UNEU1205R |
| Cutting Edge Length (L) | 0.622″ | Maximum Feed per Tooth (fz(max)) | 0.25 mm/tooth |
| Corner Radius (RE) | 0.118″ | Cutting Edge Material | Carbide |
| Insert Width (W1) | 0.622″ | Tool Type | Single sided Inserts |
| Insert Thickness (S) | 0.218″ | Minimum Feed per Tooth (fz(min)) | 0.15 mm/tooth |
| Coating | TiAlN|TiN | Measurement Type | Metric |
| Grade | IN2530 | Body Material | Carbide |
Product Features
| Family Description | UNEU1205R | Country of Origin | SOUTH KOREA |
