LNKX 1506PN-N MM IC4050
Milling Insert; 0.591″ Length × 0.236″ Width × 0.546″ Thickness ; IC4050 ; Carbide ; TiCN
| Applicable Material | | Steel | Stainless Steel | Hi Temp Alloys | | Grade | IC4050 |
| Application | | Facing | Milling Inserts | Profiling | | Shape | Rectangle |
| Cutting Edge Length (L) | 0.591″ | Maximum Feed per Tooth (fz(max)) | 0.0157 inch/tooth |
| Corner Radius (RE) | 0.031″ | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 0.276″ | Tool Type | Mill Tangential Inserts |
| Insert Width (W1) | 0.236″ | Minimum Feed per Tooth (fz(min)) | 0.0118 inch/tooth |
| Insert Thickness (S) | 0.546″ | Measurement Type | Metric |
| Coating | TiCN | Body Material | Carbide |
Product Features
| Family Description | Tangentially clamped insert with 4 L.H. and 4 R.H. cutting edges. Reinforced negative land for unfavorable conditions. Enables high feed rates on grey and nodular cast iron. | Country of Origin | Israel |
Shipping Info
Package Weight
0.031
