XNMU 130608-PNTN IC5100
Milling Insert; XNMU130608PNTN IC5100 IC5100 × 0.346″ Thickness ; Carbide ; TiCN+Al2O3
| Applicable Material | | Cast Iron | | Shape | Round |
| Application | | Bottom Shouldering | Facing | Shouldering | Side Slotting | Slotting | T Slotting | | Maximum Feed per Tooth (fz(max)) | 0.0079 ″/tooth |
| Insert Length (INSL) | 0.512″ | Cutting Edge Material | Carbide |
| Corner Radius (RE) | 0.0315″ | Tool Type | Double sided Inserts |
| Inscribed Circle Diameter (IC) | 0.512″ | Minimum Feed per Tooth (fz(min)) | 0.0031 ″/tooth |
| Insert Thickness (S) | 0.346″ | Number of Cutting Edges | 8 |
| Insert Included Angle (EPSR) | 90 Degrees | Measurement Type | Inch |
| Coating | TiCN+Al2O3 | Body Material | Carbide |
| Grade | IC5100 |
Product Features
| Family Description | Square inserts with 4 right- and 4 left-hand cutting edges | Country of Origin | Israel |
Shipping Info
Package Weight
0.030
