SEKR 42AFN-76
Milling Insert; 1/2″ Length × 1/8″ Thickness ; IC28 ; Carbide ; Uncoated
| Applicable Material | Steel|Stainless Steel|Non-Ferrous Metals|Hi-Temp Alloys | Grade | IC28 |
| Application | | Facing | Milling Inserts | Profiling | | Shape | Square |
| Cutting Edge Length (L) | 1/2″ | Maximum Feed per Tooth (fz(max)) | 0.0079 inch/tooth |
| Corner Radius (RE) | 7.94 mm | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 0.256″ | Tool Type | Single sided Inserts |
| Insert Thickness (S) | 1/8″ | Minimum Feed per Tooth (fz(min)) | 0.0047 inch/tooth |
| Wiper Edge Length (BS) | 0.071″ | Measurement Type | Metric |
| Coating | Uncoated | Body Material | Carbide |
Product Features
| Family Description | Square milling inserts with ribs along edges - reducing heat transfer, used for 45° roughing applications. | Country of Origin | Israel |
