HTR D.62-R.063-QF IC908
| Applicable Material | Steel|Stainless Steel|Cast Iron|Hard Materials|Hi-Temp Alloys | Shape | Round |
| Application | | Facing | Milling Inserts | Profiling | | Maximum Feed per Tooth (fz(max)) | 0.0059 inch/tooth |
| Corner Radius (RE) | 0.063″ | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 0.254″ | Tool Type | Single sided Inserts |
| Insert Width (W1) | 5/8″ | Minimum Feed per Tooth (fz(min)) | 0.0031 inch/tooth |
| Insert Thickness (S) | 0.133″ | Measurement Type | Metric |
| Coating | TiAlN | Body Material | Carbide |
| Grade | IC908 |
Product Features
| Family Description | Toroidal insert with a variety of corner radii, used for machining cavity fillets, pockets and for machining next to steep walls. Accuracy within 0.01mm, 2 cutting edges (fully effective). Part of the BALLPLUS multifunction milling system. | Country of Origin | Israel |
Shipping Info
Package Weight
.0240
