3M AXKT 200616R-PDR
Milling Insert; 0.858″ Length × 0.531″ Width × 0.261″ Thickness ; IC328 ; Carbide ; TiCN
| Applicable Material | Steel|Stainless Steel|Hi-Temp Alloys | Grade | IC328 |
| Application | | Facing | Milling Inserts | Profiling | | Shape | 85° Parallelogram |
| Cutting Edge Length (L) | 0.858″ | Maximum Feed per Tooth (fz(max)) | 0.0118 inch/tooth |
| Corner Radius (RE) | 0.063″ | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 0.787″ | Tool Type | Single sided Inserts |
| Insert Width (W1) | 0.531″ | Minimum Feed per Tooth (fz(min)) | 0.0059 inch/tooth |
| Insert Thickness (S) | 0.261″ | Measurement Type | Metric |
| Wiper Edge Length (BS) | 0.079″ | Body Material | Carbide |
| Coating | TiCN |
Product Features
| Family Description | MILL2000 Inserts for heavy milling applications with a variety of corner radii. Heavy duty design: dovetail section shape, helical cutting edge and positive rake angle. Enable a secure clamping and high durability in rough applications. | Country of Origin | Israel |
| Remarks | Reduce feed by 50% during engagement and exit from the workpiece. This practice will substantially increase insert life. Inserts with corner radii larger than .031″ should be used on 3M SM–20 tools only on the face of the cutter. |
Shipping Info
Package Weight
0.045
