3M AXKT 2006PDTR
Milling Insert; 0.886″ Length × 0.531″ Width × 0.268″ Thickness ; IC5100 ; Carbide ; TiCN|Al2O3
| Applicable Material | Steel|Cast Iron | Grade | IC5100 |
| Application | | Facing | Milling Inserts | Profiling | | Shape | 85° Parallelogram |
| Cutting Edge Length (L) | 0.886″ | Maximum Feed per Tooth (fz(max)) | 0.0118 inch/tooth |
| Corner Radius (RE) | 0.039″ | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 0.795″ | Tool Type | Single sided Inserts |
| Insert Width (W1) | 0.531″ | Minimum Feed per Tooth (fz(min)) | 0.0059 inch/tooth |
| Insert Thickness (S) | 0.268″ | Measurement Type | Metric |
| Wiper Edge Length (BS) | 0.12″ | Body Material | Carbide |
| Coating | TiCN|Al2O3 |
Product Features
| Family Description | MILL2000 Heavy duty design: dovetail section shape, helical cutting edge and positive rake angle. Enable a secure clamping and high durability in rough applications. | Country of Origin | Israel |
| Remarks | Reduce feed by 50% during engagement and exit from the workpiece, this practice will substantially increase insert life. |
Shipping Info
Package Weight
0.047
