HP ADKT 190640PDTR IC328
| Applicable Material | Steel|Stainless Steel|Hi-Temp Alloys | Grade | IC328 |
| Application | | Facing | Milling Inserts | Profiling | | Shape | 85° Parallelogram |
| Cutting Edge Length (L) | 0.803″ | Maximum Feed per Tooth (fz(max)) | 0.0071 inch/tooth |
| Corner Radius (RE) | 0.157″ | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 0.756″ | Tool Type | Single sided Inserts |
| Insert Thickness (S) | 0.27″ | Minimum Feed per Tooth (fz(min)) | 0.0031 inch/tooth |
| Wiper Edge Length (BS) | 0.008″ | Measurement Type | Metric |
| Coating | TiCN | Body Material | Carbide |
Product Features
| Family Description | HELIPLUS milling inserts with 19 mm cutting edge for general use. | Country of Origin | Israel |
| Remarks | Insert with corner radii larger than 1.0 mm should not be used on the HP ADK-19 cutter. |
Shipping Info
Package Weight
.0310
