OFMT 0706 AER-76
Milling Insert; OFMT 0706 AER-76 IC328 IC328 × 1/4″ Thickness ; Carbide ; TiCN
| Applicable Material | Steel|Stainless Steel|Hi-Temp Alloys | Grade | IC328 |
| Application | | Facing | Milling Inserts | Profiling | | Shape | 135° Octagon |
| Corner Radius (RE) | 0.024″ | Maximum Feed per Tooth (fz(max)) | 0.0138 inch/tooth |
| Depth of Cut Maximum (APMX) | 0.134″ | Cutting Edge Material | Carbide |
| Inscribed Circle Diameter (IC) | 0.701″ | Tool Type | Single sided Inserts |
| Insert Thickness (S) | 1/4″ | Minimum Feed per Tooth (fz(min)) | 0.0079 inch/tooth |
| Wiper Edge Length (BS) | 0.069″ | Measurement Type | Metric |
| Coating | TiCN | Body Material | Carbide |
Product Features
| Family Description | HELIOCTO, Octagonal milling inserts for general use. | Country of Origin | Israel |
Shipping Info
Package Weight
0.036
