HM90 ADCT 150550R-T IC380
Milling Insert; HM90ADCT150550RT IC380 IC380 0.637″ Length × 0.38″ Width × 0.23″ Thickness ; Carbide ; TiCN+TiN
| Applicable Material | | Hard Materials | Hi Temp Alloys | | Shape | 85° Parallelogram |
| Application | | Counter Boring | Countersinking | Drill Mill | Facing | Milling Inserts | Plunging & Recessing | Rampdown | Shouldering | Slanted Shoulder & Chamfer | Slotting | | Maximum Feed per Tooth (fz(max)) | 0.0039 ″/tooth |
| Cutting Edge Length (L) | 0.637″ | Cutting Direction (HAND) | Right Hand |
| Insert Length (INSL) | 0.637″ | Cutting Edge Material | Carbide |
| Corner Radius (RE) | 0.1969″ | Tool Type | Single sided Inserts |
| Depth of Cut Maximum (APMX) | 0.472″ | Minimum Feed per Tooth (fz(min)) | 0.0031 ″/tooth |
| Insert Width (W1) | 0.38″ | Cutting Edge Effective Length (LE) | 0.571″ |
| Insert Thickness (S) | 0.23″ | Measurement Type | Inch |
| Coating | TiCN+TiN | Body Material | Carbide |
| Grade | IC380 |
Product Features
| Family Description | HELI2000, Helical cutting edged, high 90° shoulder accuracy and surface quality inserts. Used for general use applications. | Country of Origin | Israel |
| Remarks | For inserts with corner radii larger than .079″, the cutter body and seats should be modified Inserts with corner radii larger than .031″ should be used on ADK & SM tools only on the face of the cutter. For a more economical insert refer to ADKT 1505PDR-HM in the ADKT 1505PDR family |
Shipping Info
Package Weight
0.016
