EC-E3 20-20/40C20R2.N93CE IS35
SQ End Mill; 20 mm Dia. × 15 mm LOC × 20 mm Shank Dia. × 93 mm OAL ; 3 FL ; Ceramic
| Cutting Diameter (DC) | 20 mm | Corner Radius (RE) | 2.5 mm |
| Connection Diameter Machine Side (DCONMS) | 20 mm | Ramping Angle Maximum (RMPX) | 3 Degrees |
| Depth of Cut Maximum (APMX) | 15 mm | Grade | IS35 |
| Overall Length (OAL) | 93 mm | Neck Diameter (DN) | 19.5 |
| Cutting Edge Material | Ceramic | Head Length (LH) | 40 mm |
| Coating | AlTiN | Tool Type | Center Cut |
| Flute Count (NOF) | 3 | Maximum Feed per Tooth (fz(max)) | 0.04 mm/tooth |
| Flute Helix Angle (FHA) | 30 Degrees | Minimum Feed per Tooth (fz(min)) | 0.02 mm/tooth |
| Shank Type | Round | Body Material | Carbide |
| End Shape | Corner Radius | Decimal Equivalent | 0.035″ |
| Usable Length (LU) | 39.5 mm | Measurement Type | Metric |
| Applicable Material | | Hi Temp Alloys | | Connection Code Machine Side (CCMS) | Cylindrical |
| Application | Facing | Helical Interpolation | Plunging & Recessing | Rampdown | Shouldering | Slotting |
Product Features
| Family Description | 3 and 7 Flute solid ceramic endmills with relieved necks for machining nickel base alloys, cast iron and graphite at very high cutting speed. | Country of Origin | Germany |
| Remarks | Maximum width of cut for the 3 flute cutters is 0.1xDC Maximum width of cut for the 7 flute cutters is DC Only air coolant should be used |
Shipping Info
Package Weight
0.265
