M10X1.00 D5 PM COB SEMI-BTM-TIN
Forming Tap; M10 × 1 mm ; 90 mm OAL × 35 mm LU × 7 mm Shank Dia. ; TiN ; D5 ; Series 5740
Additional Tariff Surcharge of 6.6 %
| Tool Type | Cut Tap | Thread Standard | Metric Fine |
| Thread Diameter Size (TDZ) | M10 | Application | Blind Hole |
| Thread Pitch (TP) | 1 mm | Coating | TiN |
| Overall Length (OAL) | 90 mm | Coolant Supply Property (CSP) | External |
| Usable Length (LU) | 35 mm | Helix Angle | 40 Degrees |
| Connection Diameter Machine Side (DCONMS) | 7 mm | Chamfer | 2-3 Form C |
| Flute Count (NOF) | 3 | Series/List # | 5740 |
| Drive Size (DRVS) | 5.5 mm | Thread Size | M10 × 1 |
| Thread Tolerance Class (TCTR) | D5 | Body Material | HSS-E-PM |
| Tap Standard | DIN 374 |
Product Features
| Country of Origin | Germany |
Shipping Info
Package Length
4.50000
Package Width
.56300
Package Height
.53400
Package Weight
.068
