M14X1.25 D5 PM COB DIN PLUG-TIN
Forming Tap; M14 × 1.25 mm ; 100 mm OAL × 40 mm LU × 11 mm Shank Dia. ; TiN ; D5 ; Series 5739
Additional Tariff Surcharge of 6.6 %
| Tool Type | Cut Tap | Tap Standard | DIN 374 |
| Thread Diameter Size (TDZ) | M14 | Thread Standard | Metric Fine |
| Thread Pitch (TP) | 1.25 mm | Application | Through Hole |
| Overall Length (OAL) | 100 mm | Coating | TiN |
| Usable Length (LU) | 40 mm | Coolant Supply Property (CSP) | External |
| Connection Diameter Machine Side (DCONMS) | 11 mm | Chamfer | 3.5-5 Form B |
| Flute Count (NOF) | 4 | Series/List # | 5739 |
| Drive Size (DRVS) | 9 mm | Thread Size | M14 × 1.25 |
| Thread Tolerance Class (TCTR) | D5 | Body Material | HSS-E-PM |
Product Features
| Country of Origin | Germany |
Shipping Info
Package Length
4.00000
Package Width
1.00000
Package Height
1.00000
Package Weight
.154
