Miniature End Mills - Stub & Standard - 0.0550″ Cutter Diameter × 0.0050″ Radius × 0.1650″ Length of Cut Carbide Corner Radius End Mill, 2 Flutes
SQ End Mill; 0.055″ Dia. × 0.165″ LOC × 1/8″ Shank Dia. × 1-1/2″ OAL ; 2 FL ; Carbide ; Uncoated
| Cutting Diameter (DC) | 0.055″ | Flute Count (NOF) | 2 |
| Connection Diameter Machine Side (DCONMS) | 1/8″ | End Shape | Corner Radius |
| Depth of Cut Maximum (APMX) | 0.165″ | Corner Radius (RE) | 0.005″ |
| Overall Length (OAL) | 1-1/2″ | Flute Type | Stub|Standard |
| Cutting Edge Material | Carbide | Decimal Equivalent | 0.055″ |
| Coating | Uncoated | Measurement Type | Inch |
Product Features
| Country of Origin | USA |
Shipping Info
Package Weight
0.009
