20mm Dia. × 38mm LOC 8 Flute Carbide TAX 1.5mm CR
SQ End Mill; 20 mm Dia. × 38 mm LOC × 20 mm Shank Dia. × 104 mm OAL ; 1.5 mm RE ; 8 FL ; Carbide ; AlTiN
Additional Tariff Surcharge of 8 %
| Cutting Diameter (DC) | 20 mm | Flute Count (NOF) | 8 |
| Connection Diameter Machine Side (DCONMS) | 20 mm | Flute Helix Angle (FHA) | CW|50 Degrees |
| Depth of Cut Maximum (APMX) | 38 mm | Shank Type | Round |
| Overall Length (OAL) | 104 mm | End Shape | Corner Radius |
| Cutting Edge Material | Carbide | Corner Radius (RE) | 1.5 mm |
| Coating | AlTiN | Decimal Equivalent | 0.7874″ |
Product Features
| Family Description | H8082228–20–1.5 | Country of Origin | Germany |
Shipping Info
Package Weight
1.012
