| Thread Diameter Size (TDZ) | 3/4″ | Tool Type | Machine Blind Hole Tap |
| Thread Pitch (TP) | 1.5 mm | Chamfer | 2.5P-3P |
| Threads per Inch (TPI) | 10 | Coating | Uncoated |
| Thread Standard | Metric | Flute Type | Spiral |
| Overall Length (OAL) | 4.921″ | Style | DIN 376 |
| Thread Cutting Part Length (THL) | 0.98″ | fmax | 4 |
| Usable Length (LU) | 393.66″ | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 0.551″ | Grade | HE |
| Flute Count (NOF) | 4 | d max | 3/4″" |
| Cutting Edge Material | HSS | ToolTypeName | Machine Blind Hole Taps |
| Thread Tolerance Class (TCTR) | D6 | L125 | 4.921″ |
| Standard | DIN 376 | Series/List # | 299 |
Product Features
| Family Description | HSS spiral flute machine taps for unified coarse threads, for a wide range of materials. | Country of Origin | Israel |
Shipping Info
Package Weight
.3450
