EC-A2 002-003/005C4H45 IC702
SQ End Mill; 0.2 mm Dia. × 0.3 mm LOC × 4 mm Shank Dia. × 45 mm OAL ; 2 FL ; 0.5 mm LBS ; Carbide ; AlTiCrSiN
| Cutting Diameter (DC) | 0.2 mm | Grade | IC702 |
| Connection Diameter Machine Side (DCONMS) | 4 mm | Neck Diameter (DN) | 0.17 mm |
| Depth of Cut Maximum (APMX) | 0.3 mm | Body Half Taper Angle (BHTA) | 15 Degrees |
| Overall Length (OAL) | 45 mm | Tool Type | Solid carbide center cutting endmills 90° |
| Cutting Edge Material | Carbide | Maximum Feed per Tooth (fz(max)) | 0.003 mm/tooth |
| Coating | AlTiCrSiN | Minimum Feed per Tooth (fz(min)) | 0.003 mm/tooth |
| Flute Count (NOF) | 2 | Coolant Supply Property (CSP) | External |
| Flute Helix Angle (FHA) | 30 Degrees | Body Material | Carbide |
| Shank Type | Round | Measurement Type | Metric |
| End Shape | Square | Connection Code Machine Side (CCMS) | Cylindrical |
| Usable Length (LU) | 0.5 mm | Cutting Diameter Tolerance | e8 |
| Applicable Material | | Steel | Hard Materials | | Shank Diameter Tolerance (TCDMM) | h6 |
| Application | | Drill Mill | Helical Interpolation | Plunging & Recessing | Shouldering | Slotting | |
Product Features
| Family Description | 2 flute, 30° helix and corner radii solid carbide endmills for rib processing on hard materials up to 65 HRC. | Country of Origin | S.Korea |
Shipping Info
Package Weight
0.026
