1-12 Dia. - H4-4 FL - HSSE - Bright - Modified Bottoming - Spiral Flute Tap
Spiral Flute Tap; 1″ - 12 ; 5-1/8″ OAL ; 4 FL ; HSSCo ; Uncoated ; H4 ; Series 290
| Thread Diameter Size (TDZ) | 1″ | Thread Tolerance Class (TCTR) | H4 |
| Threads per Inch (TPI) | 12 | Tool Type | High Performance Tap |
| Thread Standard | NF | Chamfer | 2.5P-3P |
| Overall Length (OAL) | 5-1/8″ | Coating | Uncoated |
| Thread Cutting Part Length (THL) | 2-1/2″ | Flute Type | Spiral |
| Usable Length (LU) | 3.011″ | Style | Modified Bottoming |
| Connection Diameter Machine Side (DCONMS) | 0.8″ | Measurement Type | Inch |
| Flute Count (NOF) | 4 | Series/List # | 290 |
| Cutting Edge Material | HSSCo |
Product Features
| Country of Origin | Brazil |
Shipping Info
Package Length
5.25000
Package Width
1.25000
Package Height
1.15000
Package Weight
.6050
