MTSR 0250 H08C
| Cutting Diameter (DC) | 0.35″ | Coolant Supply Property (CSP) | External |
| Connection Diameter Machine Side (DCONMS) | 1/4″ | Cutting Position | External |
| Depth of Cut Maximum (APMX) | 0.551″ | Measurement Type | Inch |
| Overall Length (OAL) | 4″ | Threads per Inch Maximum (TPIX) | 48 |
| Master Insert Identification (MIID) | 08IR/EL | Threads per Inch Minimum (TPIN) | 14 |
| Shank Type | Round | Grade | 3102191 |
Product Features
| Family Description | Indexable threading endmills with cylindrical shanks and coolant holes for single point inserts. | Country of Origin | Israel |
| Remarks | Minimum bore should be one-third larger than D |
Shipping Info
Package Weight
.1320
