IDK 0437 IC908
Drill Head; 0.437″ Dia. × 7.6 mm Thickness ; 140 Degrees ; IC908 ; Carbide ; TiAlN
| Cutting Diameter (DC) | 0.437″ | Cutting Edge Material | Carbide |
| Applicable Material | Steel|Stainless Steel|Cast Iron|Hard Materials|Hi-Temp Alloys | Measurement Type | Inch |
| Application | | Drilling | | Insert Thickness (S) | 7.6 mm |
| Grade | IC908 | Point Length (PL) | 2.04 mm |
| Tool Type | Drilling Heads | Point Angle (SIG) | 140 Degrees |
| Insert Seat Size Code (SSC) | 13.0 | Coating | TiAlN |
| Functional Length (LF) | 0.303″ | Body Material | Carbide |
Product Features
| Family Description | CHAMDRILLJET exchangeable drilling bits with coolant holes, for cast-iron (ISO K). The drill head is designed with a honed cutting edge and two peripheral chamfers. | Country of Origin | Israel |
Shipping Info
Package Weight
0.125
