GPB-14-40-250+3CD
| Tool Type | Deep Hole / Gun Drill | Drill Bit Size / Cutting Diameter (DC) | 3/4″ |
| Height | 0.295″ | Drill Bit Size / Cutting Diameter (DC) - Inch | 3/4″ |
| Shank Width (B) | 0.551″ | Measurement Type | Inch |
| Head Diameter | 1-3/16″ | Width (W) | 0.551″ |
| Head Length (LH) | 1.575″ | Thickness (H) | 0.295″ |
| Base OD | 1-5/16″ | Body Material | Steel |
| Overall Length (OAL) | 1.575″ |
Product Features
| Family Description | Deep drilling head guide pads. | Country of Origin | Japan |
| Remarks | Pads without grade identification are made from steel with brazed carbide tips. |
Shipping Info
Package Weight
0.09
