MTFNL24-6E-1-1/2 × 1-1/2″ SH - LH - Turning Toolholder
Turning Toolholder; 7″ OAL × 2 1/2″ Shank Height × 1 1/2″ Shank Width × 1-1/2″ Shank Dia. × 1.5 LH ; Left Hand
| Shank Height (H) | 2 1/2″ | Master Insert Identification (MIID) | TNM_66_ |
| Shank Width (B) | 1 1/2″ | End Chamfer Angle (ECA) | 0 Degrees |
| Overall Length (OAL) | 7″ | Clamping System | CL12 |
| Head Length (LH) | 1.5 | Tool Type | Turning Toolholders-Standard |
| Connection Diameter Machine Side (DCONMS) | 1-1/2″ | Style | MTFNL24-6E |
| Inscribed Circle Diameter (IC) | 3/4″ | Insert Style | MTFN |
| Cutting Direction (HAND) | Left Hand |
Product Features
| Remarks | •Style F •0° End Cutting Edge Angle for Negative Triangle TNM_ Inserts | Country of Origin | USA |
Shipping Info
Package Weight
4.700
