MSKNR12-4B-3/4 × 3/4″ SH - RH - Turning Toolholder
Turning Toolholder; 4-1/2″ OAL × 3/4″ Shank Height × 3/4″ Shank Width × 3/4″ Shank Dia. × 1.25 LH ; Right Hand
| Shank Height (H) | 3/4″ | Master Insert Identification (MIID) | SNM_43_ |
| Shank Width (B) | 3/4″ | End Chamfer Angle (ECA) | 15 Degrees |
| Overall Length (OAL) | 4-1/2″ | Clamping System | CL9 |
| Head Length (LH) | 1.25 | Tool Type | Turning Toolholders-Standard |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Style | MSKNR12-4B |
| Inscribed Circle Diameter (IC) | 1/2″ | Insert Style | MSKN |
| Cutting Direction (HAND) | Right Hand |
Product Features
| Remarks | •Style K •15° End Cutting Edge Angle for Negative Square SNM_ Inserts | Country of Origin | USA |
Shipping Info
Package Weight
.750
