FDN D200-18-40-R12
| Cutting Diameter (DC) | 200 mm | Flute Count (NOF) | 16 |
| Cutting Item Count (CICT) | 16 | Overall Length (OAL) | 50 mm |
| Peripheral Effective Cutting Edge Count (ZEFP) | 8 | Master Insert Identification (MIID) | QDMT 1205PDN-RM |
| Depth of Cut Maximum (APMX) | 18 mm | Application | | Bottom Shouldering | Facing | Shouldering | Side Slotting | Slotting | T Slotting | |
| Cutting Depth Maximum (CDX) | 54 mm | Arbor Style | C |
| Connection Diameter Machine Side (DCONMS) | 31.75 mm | Tool Type | Double-sided slotting cutters |
| Hub Diameter (DHUB) | 92 mm | Measurement Type | Metric |
| Cutting Width Maximum (CWX) | 10 mm | Body Material | Steel |
| Usable Length (LU) | 50 mm |
Product Features
| Family Description | HELIQUAD, Full slot, flange-type slotting cutters. | Country of Origin | Israel |
| Remarks | For fully effective conditions, click on "More Info". |
Shipping Info
Package Weight
8.047
