SDN D8.0-0.75-16-12
| Cutting Diameter (DC) | 8″ | Flute Count (NOF) | 14 |
| Cutting Item Count (CICT) | 14 | Overall Length (OAL) | 7/8″ |
| Peripheral Effective Cutting Edge Count (ZEFP) | 7 | Master Insert Identification (MIID) | QDMT 1205PDN-RM |
| Depth of Cut Maximum (APMX) | 3/4″ | Application | | Bottom Shouldering | Side Slotting | Slotting | |
| Cutting Depth Maximum (CDX) | 2.43″ | Tool Type | Double-sided slotting cutters |
| Connection Diameter Machine Side (DCONMS) | 2″ | Measurement Type | Inch |
| Hub Diameter (DHUB) | 3″ | Body Material | Steel |
| Cutting Width (CW) | 3/4″ | Connection Code Machine Side (CCMS) | Disk type |
Product Features
| Family Description | Full slot disk type slotting cutters carrying square inserts. | Country of Origin | Israel |
Shipping Info
Package Weight
7.039
