3VL5V0805058R01 V-MAX
| Cutting Diameter (DC) | 8″ | Cutting Width Maximum (CWX) | 10 mm |
| Peripheral Effective Cutting Edge Count (ZEFP) | 8 | Usable Length (LU) | 35 mm |
| Connection Diameter Machine Side (DCONMS) | 31.75 mm | Flute Count (NOF) | 16 |
| Hub Diameter (DHUB) | 3.8″ | Arbor Style | Arbor Hole |
| Hub Thickness (THUB) | 2″ | Measurement Type | Inch |
| Cutting Width (CW) | 1/2″ |
Product Features
| Family Description | Width of Cut: .375″ and .500″ (4 indexes) Insert Corner: .031″R | Country of Origin | USA |
Shipping Info
Package Weight
13.26
