SDN D5.00-.156-10-LN08
| Cutting Diameter (DC) | 5″ | Usable Length (LU) | 35 mm |
| Cutting Item Count (CICT) | 16 | Flute Count (NOF) | 16 |
| Peripheral Effective Cutting Edge Count (ZEFP) | 8 | Overall Length (OAL) | 0.312″ |
| Cutting Depth Maximum (CDX) | 1.54″ | Master Insert Identification (MIID) | LNET 082604-TN-N |
| Connection Diameter Machine Side (DCONMS) | 31.75 mm | Application | | Side Slotting | Slitting | Slotting | |
| Hub Diameter (DHUB) | 1-3/4″ | Arbor Style | Arbor Hole |
| Hub Thickness (THUB) | 0.312″ | Tool Type | Double-sided slotting cutters |
| Cutting Width Maximum (CWX) | 0.175″ | Measurement Type | Inch |
| Cutting Width Minimum (CWN) | 0.156″ | Body Material | Steel |
Product Features
| Family Description | Disk type grooving and slitting cutters carrying tangentially clamped inserts with 4 cutting edges. | Country of Origin | Israel |
Shipping Info
Package Weight
1.323
