SDN D10-.68-.9-20-CALN13
| Cutting Diameter (DC) | 10.039″ | Flute Count (NOF) | 16 |
| Cutting Item Count (CICT) | 16 | Overall Length (OAL) | 1-1/4″ |
| Peripheral Effective Cutting Edge Count (ZEFP) | 8 | Master Insert Identification (MIID) | T490 LNHT 1306PNTR |
| Cutting Depth Maximum (CDX) | 2.98″ | Application | | Bottom Shouldering | Shouldering | Side Slotting | Slotting | |
| Connection Diameter Machine Side (DCONMS) | 31.75 mm | Arbor Style | Arbor Hole |
| Hub Diameter (DHUB) | 3-1/2″ | Tool Type | Double-sided slotting cutters |
| Cutting Width Maximum (CWX) | 0.9″ | Measurement Type | Inch |
| Cutting Width Minimum (CWN) | 0.69″ | Body Material | Steel |
| Usable Length (LU) | 35 mm |
Product Features
| Family Description | Full slot adjustable slotting cutters with cartridges carrying tangentially mounted T490 LNHT 1306PNTR/L inserts. Each cutter body can be changed into full slot, bottom or top milling configuration, by mounting the cartridges accordingly. | Country of Origin | Israel |
| Remarks | Each cutter body can be changed into full slot, bottom or top milling configuration by mounting the cartridges accordingly Half of the inserts are used on right-hand cartridges and half on left-hand cartridges Gang-mill assembly SDN and left-hand SSB cutters feature two keyways To reduce vibration, it is recommended to assemble gang-mills with alternating keyway position. For cutting recommendations, click on "More Info" |
Shipping Info
Package Weight
0.2
