DD6H-60R01
Indexable Face Mill; 6″ Dia. × 1-1/2″ Shank Dia. × 2-3/8″ OAL × 0.065″ LOC ; 13 Inserts ; 12.5 Degrees
| Cutting Diameter (DC/DCX) | 6″ | Hub Diameter (DHUB) | 2.48″ |
| Cutting Diameter (DC) | 5.253″ | Arbor Style | A |
| Cutting Diameter Maximum (DCX) | 6″ | Coolant Supply Property (CSP) | External |
| Cutting Item Count (CICT) | 13 | Body Material | Steel |
| Depth of Cut Maximum (APMX) | 0.065″ | Application | | Facing | Helical Interpolation | Plunging & Recessing | Rampdown | Slotting | |
| Connection Diameter Machine Side (DCONMS) | 1-1/2″ | Measurement Type | Inch |
| Overall Length (OAL) | 2-3/8″ | Tool Cutting Edge Angle (KAPR) | 12.5 Degrees |
Product Features
| Country of Origin | Usa |
Shipping Info
Package Weight
0.014
