H690 FWN D3.00-07-1.25R07
Indexable Face Mill; 3″ Dia. × 1-1/4″ Shank Dia. × 1-3/4″ OAL × 0.275″ LOC ; 7 Inserts ; 90 Degrees
| Cutting Diameter (DC/DCX) | 3″ | Master Insert Identification (MIID) | H690 WNMU 0705-PNTR |
| Cutting Diameter (DC) | 3″ | Coolant Supply Property (CSP) | Coolant Thru |
| Cutting Item Count (CICT) | 7 | Body Material | Steel |
| Depth of Cut Maximum (APMX) | 0.275″ | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 1-1/4″ | Application | | Facing | Helical Interpolation | Rampdown | Shouldering | Slotting | |
| Overall Length (OAL) | 1-3/4″ | Measurement Type | Inch |
| Hub Diameter (DHUB) | 2-3/4″ | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Arbor Style | A | Tool Type | 90° Facemills |
Product Features
| Family Description | 90° face mills carrying H690 WNMU 0705 double-sided trigonal inserts with 6 helical cutting edges. | Country of Origin | Israel |
Shipping Info
Package Weight
4.629
