ISC-IC 1.575-1.731
| Application | | Deep Drilling | | Coolant Supply Property (CSP) | Coolant Thru |
| Connection Diameter Machine Side (DCONMS) | 1.299″ | Connection Thread Size (Ts) | TS-O16 |
| Tool Type | Deep Hole / Gun Drill | Cutting Diameter Minimum (DCN) | 1.575″ |
| Shank Length (LS) | 1.575″ | Cutting Diameter Maximum (DCX) | 1.731″ |
| Functional Length (LF) | 5.315″ | Measurement Type | Inch |
| Overall Length (OAL) | 5.315″ | Body Material | Steel |
Product Features
| Family Description | Deep single tube counterbores with a through hole, internal single start thread connection and a cartridge. Each item represents a diameter range. For a specific head diameter, an order form should be filled out. | Country of Origin | Japan |
| Remarks | CAOD - Rough boring cartridge (large D.O.C.) CAORC - Precision boring cartridge Supplied with CAOD cartridge, unless ordered differently For quotation form and user guide, click on More Info |
